Pixel Matrix 2500x 3052
Effective Area 347.8x 425.04mm
Effective Array 2484 x 3036
Image Performance
- Spatial Resolution 3.4 lp/mm 3.4 lp/mm
- ADC Resolution 16 bits
- Grayscale 65536 grayscales
X-ray voltage Range 40 ~ 150 Kvp
X-ray Generator Interface Line Trigger(Manual)/ Auto Trigger(AED Mode)
Dimensions: (384x460x15mm)
Windows 7/8/10: Support for 32/64bits Windows
Power/ Environment
Wired DC +15V
Wireless Max. 1 Pack(Battery/11.8V/ 4 hour)
Environment T(10~+40)/H(20 ~ 75%)/P(70~106KPa)
