Performance

➡️Technical Specifications:
➡️Safety Standard:IEC,ClassI,Type CF
➡️Input Circuit:Floating, Protection against defibrillator and pacemaker
➡️Lead:Standard 12 lead
➡️Input Impendence: ≥50MΩ
➡️Patient Current Leakage: < 10 A
➡️Calibraiton Voltage:1mV±2%
➡️Depolarization Voltage: ±500Mv
➡️Ampling Rate:1.0ms(1000Hz)
➡️A/D Constant:>12 bits
➡️Frequency Response:0.05Hz~165Hz(-3Db)
➡️Time constant: :>3.2s
➡️Noise Level: < 15 Vp-p
➡️CMRR: >100 Db
➡️Digital Filters:HUM,EMG,ADS
➡️Sensitivity:Auto,2.5,5,10,20mm/Mv(±2%)
➡️Measurement:Heart rate,PR Int,Vent,Rate,P/QPS/T Axis
➡️Patient Data :Date,Time,ID, Name,Gender ,age,height,weight,blood pressure,etc.
➡️System Data:Sensitivity,Paper Speed,Filter on/off,hospital name,etc.
➡️Print-out:Vaveform,waveform+measurement report,or waremfor+measurement report+analysisi report
➡️Printing system: High speed, high sensitivity thermal matrix pringint system
➡️Paper Speed:6.25,12.5,25,50mm/s(±3%)
➡️Printing Paper 216mmx30m roll paper
➡️Power Supply: Power Supply: AC 110/220v,50/60Hz DC 14.4V/2Ah,Built-in rechargeable lithium batter
➡️Size &Weight: G.W/N.W:5.5kgs/3.5kgs
