Minimum Dose · Maximum Diagnostic Accuracy by QX Platform
High DQE / MTF Value
Ultimate Image sharpness with TRUVIEW®ART
DEPAI™ AI Imaging Processing

Specifications

• Technology IGZO TFT
• Scintillator Csl
• Pixel Pitch 140 ㎛
• Pixel Matrix 3072 x 3072 pixels
• Data Interface (Wired) Gigabit Ethernet
• Dimensions 46.0 ㎝ × 48.3 ㎝ × 1.55㎝
• Weight 4.3 kg
• A/D Conversion 16 bits
• X-ray Voltage Range 40 - 150 kVp
• Operating Environment
• Temp. Operating 10°C to 35°C
• Humidity (non-condensing) 10% to 90 % RH
