• Halogen illumination with 6V 30W halogen lamp
• 4-position nosepiece, tilted backwards
• Mechanical stage 75x30, drive right and specimen holder
• Binocular tube 30°/20
• Eyepieces 10x/20 Br.foc.
• Objectives Plan-Achromat 10x Ph1, 20x Ph2, 40x Ph2
• Condenser 0.9/ 1.25 with H, Ph1, Ph2, Ph3 phase contrast slider
• Pinhole diaphragm, d=30mm external power unit 100...240VAC/50...60Hz/30VA with country-specific adapters dust cover
• Interference filter green, d=45 mm for phase contrast 6V 30W halogen lamp
|
